Miller 907816 TIG Welder Dynasty 210, AC/DC, Power Source Only, 150 A/210 A, 8 ft Power Cord Lg - KVM Tools Inc.KV794JW3

Miller 907816 TIG Welder Dynasty 210, AC/DC, Power Source Only, 150 A/210 A, 8 ft Power Cord Lg

UPC: 715959698092 | Harmonization / Schedule B : 8515.39.0040

Country of Origin: | Shipping Weight:

$7,924.25 - $7,924.25
$7,924.25
$7,924.25 - $7,924.25
$7,924.25
TIG Welder, For Material Type Aluminum, Stainless Steel, Steel, For Maximum Material Thickness 1/4 in (Aluminum), 1/4 in (Stainless Steel), For Minimum Material Thickness 0.012 in (Aluminum), 0.012 in (Stainless Steel), Input Frequency 50/60 Hz, Max. Input Current 26 A @ 120V (Single-Phase), Phase Single-/Three-Phase, Polarity AC/DC, Series Dynasty 210, Stick Welding Maximum Output Current 210 A, Stick Welding Minimum Output Current 5 A
Item TIG Welder
Series Dynasty 210
Polarity AC/DC
Input Frequency 50/60 Hz
Remote Control No
Welding Mode CC
Stick Welding Maximum Output Current 210 A
For Material Type Aluminum, Stainless Steel, Steel
For Maximum Material Thickness 1/4 in (Aluminum), 1/4 in (Stainless Steel)
Max. Input Current 26 A @ 120V (Single-Phase)
Pulse Frequency 0.1 to 500 pulses/second
Color Blue; Black
Weight 46 lb
Model 907816
Amperage Range 2 to 210 A
TIG Welding Maximum Output Current 150 A, 210 A
Remote Connection Type 14-Pin (Miller)
TIG Welding Output @ Duty Cycle 125 A @ 15 V, 60%, 210 A @ 18.4 V, 60%
TIG Welding Minimum Output Current 1 A, 2 A
Power Cord Included Yes
For Minimum Material Thickness 0.012 in (Aluminum), 0.012 in (Stainless Steel)
Stick Welding Minimum Output Current 5 A
Open Circuit Voltage 80 VDC
Stick Welding Output @ Duty Cycle 160 A @ 26.4 V, 60%, 90 A @ 23.6 V, 60%
TIG Arc Start Feature High Frequency Start
Input Voltage (Nominal) 120V, 480V
Rated Output at Duty Cycle (TIG) 125 A @ 60%, 210 A @ 60%
Max. Amperage Range (TIG) 150 A - 300 A
Process Stick Welding (SMAW), TIG Welding (GTAW)
Welder Kit Type Power Source Only
Plug Type Bare Leads
