| Action Type |
Rotary |
| For Media Type |
Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, DEF, Diesel Fuel, Ethylene Glycol, Glycerin, Hydraulic Oils, Kerosene, Motor Oils, Stoddard Solvent, Windshield Washer Fluid |
| Max. Flow Rate |
9.6 oz per stroke |
| Max. Viscosity |
1,500 SUS |
| Wetted Materials |
Buna-N, Cast Iron |
| Suction Tube ID |
1 in |
| Max. Fluid Temp. |
120 Degrees F |
| Discharge Tube Outlet ID |
3/4 in |
| Food Grade |
No |
| Includes |
1 1/2 in and 2 in NPT Bung Mounts, No Drip Valve, Pail Spout, Telescoping Steel Suction Pipe |
| Suction Tube OD |
1 1/8 in |
| Metered |
No |
| Discharge Tube Outlet OD |
7/8 in |
| Runs Dry |
Yes |
| Includes Suction Tube |
Yes |
| Diesel Exhaust Fluid Compatible |
No |
| Type |
Pail Spout |
| Features |
Rotary Action Hand Pump w/ 2 in NPT inlet |
| GPM |
7.5 |
| Pump Body Material |
Cast Iron |
| For Use With |
Machine Oil and Petroleum Products |
| Application |
To Transfer Diesel, Kerosene, Machine Oil, Petroleum Products |
| Item |
Hand Operated Drum Pump |
| Housing Material |
Cast iron |
| Self-Priming |
Yes |
| Adapter Material |
Cast Iron |
| Suction Tube Material |
Steel |
| Seal Material |
Buna-N |
| Min. Operating Temp. |
0 Degrees F |
| Max. Head - Pumps |
6 ft |
| Not Recommended Chemicals |
Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Acetone, Ammonia (Liquids), Ammonium Hydroxide, Anhydrous Ammonia, Calcium Chloride, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Citric Acid 50%, Cyclohexane, DEF, Deionized Water, E85, Ethyl (Ethanol), Ethyl Acetate, Fertilizers, Formic Acid, Fresh Water, Fungicides, Heptane, Herbicides, Hexane, Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Isopropyl (Isopropanol), Lacquer Thinners, Lithium Grease, Methyl (Methanol), Methyl Chloride, Methyl Ethyl Ketone (MEK), Naphtha, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Paint, Paint Thinner, Pesticides, Phosphoric Acid (40% Solution), Potassium Hydroxide (50%), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Sodium Hypochlorite/Bleach (to 20%), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Sulfuric Acid (to 10%), Toluene, Trichlorethylene (50%), Turpentine, Windshield Washer Fluid, Xylene |
| Power Source |
Hand Operated |
| Includes Bung Adapter |
Yes |
| Max. Oil Flow |
9.6 oz per stroke |
| Includes Discharge Hose |
No |
| Pump Connection ID |
2 in |
| Includes Spout |
Yes |
| Includes Nozzle |
No |
| Housing Material - Pumps |
Cast Iron |
| Pump Connection OD |
2 1/8 in |
| Max. Head Pressure |
50 psi |
| Compatible Chemicals |
Antifreeze, Automatic Transmission Fluid, Biodiesel, Brake Fluid, Diesel Fuel, Ethylene Glycol, Glycerin, Hydraulic Oils, Kerosene, Motor Oils, Stoddard Solvent, Windshield Washer Fluid |
| For Container Type |
Drum |
| Spout Material |
Aluminum |
| Grease |
NT |
| Adapter Connection Type |
NPT |
| Gear Lube |
NT |
| Max. Outlet Pressure |
50 psi |
| Mount Type |
Bung |
