| Air Inlet |
1/2 in NPT |
| Blows per Minute |
500 |
| Duty |
General |
| Free Speed |
5,200 RPM |
| Handle Type |
D-Handle |
| Housing Material |
Aluminum |
| Max. Bolt Capacity |
1 in |
| Max. Torque |
1920 ft.-lb. |
| Torque Range |
370 to 1475 ft.-lb. |
| Body Style - Air Tools |
D-Handle |
| Handle Material |
Aluminum |
| Blows per Minute - Air Tools |
500 |
| Retainer Type |
Friction Ring, Through Hole |
| Duty Cycle - Air Tools |
General Duty |
| Required Pressure |
90 PSI |
| UPC |
015451701321 |
| Item - Air Impact Wrenches |
Air Impact Wrench |
| Features |
Ergonomic Side Handle, Full Teasing Trigger, Integrated Protective Cover On The Clutch Housing, Low Vibration For A Better Operator Comfort |
| Style |
D-Handle |
| Retainer Type - Air Impacts |
Ring / Thru Hole |
| Anvil |
Standard |
| CFM @ Full Load |
40.7 |
| Average CFM @ 15 Second Run Time |
10.00 |
| Anvil Type - Air Impacts |
Standard |
| Tool Weight |
22.2 lb |
| Standards |
EN ISO 11148-6:2013, ISO 15744, ISO-28927-2 |
| Duty Rating |
General Duty |
| Max. Air Pressure |
90 psi |
| Fastening Torque |
1,475 ft-lb |
| Vibration Level |
7.8 m/sq sec |
| Power Source |
Air Powered |
| Min. Air Pressure |
90 psi |
| Impact Rated |
Yes |
| Impact Sound Level |
111 dB |
| Breakaway Torque |
1,920 ft-lb |
| Air Pressure |
90 psi |
| Exhaust Location |
Bottom |
| Power to Weight Ratio |
86.5 ft-lb/lb |
| Clutch Style |
Rocking Dog |
| Impacts per Minute |
500 |
| Tool Style |
Compact |
| Number of Speed Settings |
3 |
| Air Consumption |
41 cfm |
| Drive Type |
Standard |
| Built-In Light |
No |
