McMaster 4810T239 British Standard Low-Pressure 304 Stainless Steel Pipe Fitting Straight Adapter, 2 BSPT Male x NPT Male

Name: McMaster 4810T239 British Standard Low-Pressure 304 Stainless Steel Pipe Fitting Straight Adapter, 2 BSPT Male x NPT Male
Brand: McMaster-Carr
SKU: KV4810T239
Price: 126.23 USD
Availability: InStock

UPC: | Harmonization / Schedule B : 7307.29.0000

Country of Origin: China | Shipping Weight: 2 lbs

$126.23 - $126.23

$126.23

$126.23 - $126.23

$126.23

Quantity

Use these fittings in a low-pressure pipe line.

304 stainless steel fittings have very good corrosion resistance.

For Use With	Air, Natural Gas, Oil, Steam, Water
Shape	Straight
Type	Adapter
Body Shape	Hex
Material	304 Stainless Steel
Pressure Class	150
Fabrication	Heat Treated
Connection Type	Pipe
Connection Style	Threaded
Connection	BSPT Male × NPT Male
Pipe Size	2
Length	2 9/16"
Hex Width	2 7/16"
For Pipe
Schedule	40
Material	304 Stainless Steel, 304/304L Stainless Steel
For Flange
Class	150
Material	304 Stainless Steel, 304/304L Stainless Steel
Specifications Met	ASME B1.20.1, DIN EN 10226
System of Measurement	Inch
Maximum Steam Pressure	150 psi @ 350° F
Maximum Pressure	300 psi @ 72° F
RoHS	RoHS 3 (2015/863/EU) Compliant
REACH	REACH (EC 1907/2006) (01/17/2023, 233 SVHC) Compliant
DFARS	Specialty Metals COTS-Exempt
Country of Origin	Peoples Republic of China
Schedule B	730729.0000
ECCN	2B999
